Pilz PNOZ s50 - Password Protection for Configuration; Chip Card for Configuration Storage

Commissioning
OperatingManualPNOZs50
1002194EN02
33
NOTICE
Pleasenotethatallparametersaresettotheirdefaultvaluesondelivery.
Pleasecheckallthesafetyrelatedparametersatleast,andenterthevalues
thatcorrespondtoyourapplication.
6.2.3 Passwordprotection
Theconfigurationispasswordprotected.
}
Parameterscanonlybechangedonceapasswordhasbeenentered.
}
Factorysettingforthepassword:000000
}
Thepaswordconsistsof6figuresintherange000000…999999.
}
Thepasswordcanbechangedatanytimeinthemenu.
INFORMATION
– Pleasenote:Remembertheassignedpassword.Withoutthispass
wordyouwillnotbeabletochangetheconfiguration.
– Fordetailsofhowtoenterthepassword,seethesectionentitled
"Statusdisplayandconfiguration",Level2:Enteringthepassword.
– Fordetailsofhowtochangethepassword,seethesectionentitled
"Statusdisplayandconfiguration",Level3:Configuration.
6.2.4 Usechipcard
Theparametersthataresetonadevicearestoredonthechipcard.Thedataisstored
alongwithadeviceidentifierandchecksum.Werecommendthatyoualwaysoperatethe
devicewithachipcard.
Whenthechipcardisinsidethedevice:
}
Thechipcardischeckedtoverifythedeviceidentifier,validparameters,andensure
thatthedataisidentical.
}
Deviceparametersareautomaticallysavedtothechipcardduringconfiguration.Asa
result,thechipcardalwayscontainsacopyofthedevice'scurrentinternaldata.
WhenthedeviceisswitchedoninthePowerOnoperatingstate(allLEDsilluminate
briefly)atestiscarriedouttocheckwhether
}
achipcardisinsertedorjustanemptychipcardholder
}
dataonthechipcardmatchesthedatainthedevice
}
dataonthechipcardisvalid.
