6.2 Displaymenuandconfiguration
Themenusettingsaremadeontheunit'sdisplayviaarotaryknob.Youhavetheoptionto
makethesettingsontheknobbyhandorwithascrewdriver.Ifyoumakethesettingswith
ascrewdriver,theknobcanremainwithintheunit.
NOTICE
Thecorrectdisplayofconfigurationdataandmessagesarepartofthe
device'ssafetyconcept.Ifthedisplayisfaulty(e.g.pixelsaremissing,faulty
lettersornumbers),thedevicemustbetakenoutofservice.
6.2.1 Operaterotaryknob
Therotaryknob:
}
(A)shouldbepulledoutuntilitclicksintoposition
}
(B)thenreleasedandretractedbackintotheunit:
– Pressthelatchonthesideoftherotaryknob(1)towardsthecentreoftheknob.
Thisreleasestherotaryknob.
– Presstheknobdownwards(2)whilekeepingthelatchhelddown.
6.2.2 Configuredevice
Thesettingsaremadeviatherotaryknob,asfollows:
Presstheknob
}
Confirmselection/setting
}
Switchtomenu
Rotateknob
}
Selectmenulevel
}
Settheparameter/numericvalue
Thedisplayisbacklit.Itis
}
switchedonbyturningorpressingtherotaryknob.
}
switchedoffiftherotaryknobhasnotbeenoperatedfor30seconds.
