Commissioning
OperatingManualPNOZs50
1002194EN02
30
6.1.6 Inputs
6.1.6.1 Fastshutdown
Activationviasafesinglepole
outputs
LinkY12–Y13
LinkY22–Y23
PLC:Safetycontrolsystem
Y10
Y11
Y12
Y13
O1
O2
Y20
Y21
Y22
Y23
O3
O4
PLC
PNOZ s50
Activationviasafedualpole
outputs
LinkY10–Y11
LinkY20–Y21
PLC:Safetycontrolsystem
Y10
Y11
Y12
Y13
O1+
O1-
Y20
Y21
Y22
Y23
O2+
O2-
PLC
PNOZ s50
