Pilz PNOZ s50 User Manual

Installation
OperatingManualPNOZs50
1002194EN02
24
5 Installation
5.1 Generalinstallationguidelines
Controlcabinetinstallation
}
TheunitshouldbeinstalledinacontrolcabinetwithaprotectiontypeofatleastIP54.
}
FitthedevicetoahorizontalDINrail.Theventingslotsmustfaceupwardsanddown
wards.Othermountingpositionscoulddestroythedevice.
}
UsethelockingelementontherearofthedevicetoattachittotheDINrail.
}
PushthedeviceupwardsordownwardsbeforeliftingitfromtheDINrail.
CAUTION!
Damageduetoelectrostaticdischarge!
Electrostaticdischargecandamagecomponents.Ensureagainstdischarge
beforetouchingtheproduct,e.g.bytouchinganearthed,conductivesur
faceorbywearinganearthedarmband.
5.1.1 Dimensions
*withspringloadedterminals
120 (4.72")
* 100 (3,94")
98 (3.86")
45
(1.77")
