Technicaldetails
OperatingManualPNOZs50
1002194EN02
64
9.1 Safetycharacteristicdata
Operating
mode
ENISO
138491:
2008
PL
ENISO
138491:
2008
Category
ENIEC
62061
SILCL
ENIEC
62061
PFH
D
[1/h]
IEC61511
SIL
IEC61511
PFD
ENISO
138491:
2008
T
M
[year]
All PLe Cat.4 SILCL3 7,83E10 SIL3 6,81E05 20
Alltheunitsusedwithinasafetyfunctionmustbeconsideredwhencalculatingthesafety
characteristicdata.
INFORMATION
Asafetyfunction'sSIL/PLvaluesarenotidenticaltotheSIL/PLvaluesof
theunitsthatareusedandmaybedifferent.Werecommendthatyouuse
thePAScalsoftwaretooltocalculatethesafetyfunction'sSIL/PLvalues.
Thesafetyrelatedcharacteristicdata(PFH,PFD)aremeanvalues.Theyhavebeencalcu
latedatanaverageambientcomponenttemperatureof40°Candapplyfortheambient
temperaturerangestatedinthetechnicaldetails.
