3 Touch [Calibrate].
A message confirming whether to start the ca-
libration appears.
4 Touch and hold the target that point to
the center and corners of the LCD screen.
The target indicates the order.
5 Touch anywhere on the screen.
The adjusted position data will be saved.
p Do not turn off the engine while saving the
adjusted position data.
Correcting the current location
Touch the screen to adjust the current position
and direction of the vehicle displayed on the
map.
1 Display the “Navigation Menu” screen.
2 Touch [Settings].
The “Settings Menu” screen appears.
3 Touch [Location].
4 Scroll to the position where you want
to set, then touch [OK].
Checking the connections
of leads
Check that leads are properly connected be-
tween the navigation system and the vehicle.
Please also check whether they are connected
in the correct positions.
1 Display the “Navigation Menu” screen.
2 Touch [Settings].
The “Settings Menu” screen appears.
3 Touch [Connection].
The “Connection” screen appears.
1 GPS Status
Indicates the connection status of the GPS
antenna, the reception sensitivity and from
how many satellites the signal is received.
Color
Signal com-
munication
Used in posi-
tioning
Orange Yes Yes
Yellow Yes No
2 Hand Brake
When the parking brake is applied, [On]is
displayed. When the parking brake is re-
leased, [Off] is displayed.
3 Illumination
When the headlights or small lamps of a ve-
hicle are on, [On] is displayed. When the
small lamps of a vehicle are off, [Off] is dis-
played. (If the orange/white lead is not con-
nected, [Off] appears.)
Checking the version
information
1 Display the “Navigation Menu” screen.
2 Touch [Settings].
The “Settings Menu” screen appears.
3 Touch [Service Info].
The “Service Information Screen” screen ap-
pears.
4 Check the version information.
Modifying the general settings for navigation functions
En
63
Chapter
11
Modifying the general settings for navigation functions
To Next Page
