Pioneer PDP-5071PU User Manual

PDP-5071PU
110
1234
1234
C
D
F
A
B
E
×4
Access to PCB Assys
2
1
Remove the four screws.
2
Remove the two screws.
3
Remove the four screws.
4
Remove the side input panel (U).
SIDE Assy
1
Remove the two screws.
2
Remove the side input shield with PCB.
50 X DRIVE Assy
1
Remove the two screws.
2
Remove the function button shield with PCB.
50 Y DRIVE Assy
1
Disconnect cables, connectors, as required.
2
Remove the two screws.
3
Remove the two screws.
4
Remove the two hex. head screws.
5
Remove the POD cover.
6
Remove the POD stay A with PCB.
MAIN Assy
2
1 1
3
×2
4
2
1
1
1 1
4
5
2
Side input panel (U)
Side input shield
Function button shield
SIDE KEY Assy
POD Assy
POD cover
MAIN Assy
50 Y DRIVE Assy 50 X DRIVE Assy
POD stay A
SIDE Assy
1
2
3 3
2
1
6
2
