Pioneer PDP-5071PU User Manual

PDP-5071PU
111
5678
56
7
8
C
D
F
A
B
E
×16
Terminal Panel B (50U)
3
1
Remove the 16 screws.
2
Remove the 10 screws.
3
Remove the four screws.
4
Remove the terminal panel B (50U).
4
Terminal panel B (50U)
3
2
2
2
2
2
2
2
2
2
1
3
3
3
2
Front Case Assy
4
1
Remove the four rivets.
2
Remove the Front Case Assy (507PU).
×4
1
2
-1
2
-2
Front case
1
Turn it not to press the rivet.
(Because when the rivet presses, fit in once again.)
Rivet
