Pin Function
2.3 I2C bus interface terminal
Acronyms Terminal number I/O Level Buffer type
PU/PD [kΩ]
Functions
RGRED 75 O LVTTL
N-ch open drain
6 mA I
2
C register lead flag output (Active-Low)
SCL 71 I LVTTL Fail-safe I
2
C bus clock input
Connect to the SCL line of the system.
SDA 72 I/O LVTTL
N-ch open drain
Fail-safe
6 mA
I
2
C bus data input/output
Connect to the SDA line of the system.
SLA0 73 I LVTTL – I
2
C bus slave address selection input
(L : B8h/B9h, H : BAh/BBh )
Connect to GND when set to low level and to
DVDD3 (3.3V) when set to high level.
2.4 Terminal for test
Acronyms Terminal number I/O Level Buffer type
PU/PD [kΩ]
Functions
SCKSET 2 I LVTTL – Test mode selection (L: normal, H: test mode)
TEST 3 I LVTTL – Test setting (L: normal, H: test mode)
FCKM 77 I LVTTL – FCLK8 test mode selection
(L: normal, H: test mode)
BCKM 111 I LVTTL – Test mode selection of BCLK8 terminal.
(L: normal, H: test mode)
ATS1 139 I Analog – Analog test input
Connect to GND normally.
ATS2 140 I Analog – Analog test input
Connect to GND normally.
ATS3 142 I Analog – Analog test input
Connect to GND normally.
VLPF1 149 O Analog – Analog test output
Connect to GND via a 0.1µF capacitor.
VLPF2 171 O Analog – Analog test output
Connect to GND via a 0.1µF capacitor.
Caution: Connect these terminals for test to GND unless otherwise instructed.
