Pioneer PDP-5071PU User Manual

PDP-5071PU
66
1234
1234
C
D
F
A
B
E
No. Name Name No. No. Name Name No.
1 INPUT2_PR 2.5 INPUT2_PR 50 1 MON_OUT_V 1.5 MON_OUT_V 40
2 GND 0 GND 49 2 GND 0 GND 39
3 INPUT2_PB 2.5 INPUT2_PB 48 3 INPUT1_L 4.5 INPUT1_L 38
4 GND 0 GND 47 4 GND 0 GND 37
5 INPUT2_Y 2.5 INPUT2_Y 46 5 INPUT1_R 4.1 INPUT1_R 36
6 GND 0 GND 45 6 GND 0 GND 35
7 INPUT2_PLUG 2.5 INPUT2_PLUG 44 7 INPUT2_L 4.5 INPUT2_L 34
8 GND 0 GND 43 8 GND 0 GND 33
9 INPUT3_PR 2.5 INPUT3_PR 42 9 INPUT2_R 4.5 INPUT2_R 32
10 GND 0 GND 41 10 GND 0 GND 31
11 INPUT3_PB 2.5 INPUT3_PB 40 11 SW_OUT 0.5 SW_OUT 30
12 GND 0 GND 39 12 GND 0 GND 29
13 INPUT3_Y 2.5 INPUT3_Y 38 13 MON_OUT_L 0.7 MON_OUT_L 28
14 GND 0 GND 37 14 GND 0 GND 27
15 INPUT6_L 4.6 INPUT6_L 36 15 MON_OUT_R 1 MON_OUT_R 26
16 GND 0 GND 35 16 GND 0 GND 25
17 INPUT6_R 4.6 INPUT6_R 34 17 REM_B 4.8 REM_B 24
18 GND 0 GND 33 18 SR_IN 4.8 SR_IN 23
19 INPUT5_L 4.6 INPUT5_L 32 19 TXD_SR4 3.2 TXD_SR4 22
20 GND 0 GND 31 20 RXD_SR4 3.2 RXD_SR4 21
21 INPUT5_R 4.6 INPUT5_R 30 21 GND 0 GND 20
22 GND 0 GND 29 22 PC_LCH 4.6 PC_LCH 19
23 INPUT3_L 4.6 INPUT3_L 28 23 GND 0 GND 18
24 GND 0 GND 27 24 PC_RCH 4.6 PC_RCH 17
25 INPUT3_R 4.6 INPUT3_R 26 25 GND 0 GND 16
26 GND 0 GND 25 26 GND 0 GND 15
27 INPUT1_V 2.6 INPUT1_V 24 27 V+5V_A 4.9 V+5V_A 14
28 GND 0 GND 23 28 INPUT4_PLUG 4.9 INPUT4_PLUG 13
29 INPUT1_SC 2.1 INPUT1_SC 22 29 GND 0 GND 12
30 INPUT1_S2 0.2 INPUT1_S2 21 30 INPUT4_Y 2.5 INPUT4_Y 11
31 INPUT1_SPLUG 4.9 INPUT1_SPLUG 20 31 GND 0 GND 10
32 INPUT1_SY 2.6 INPUT1_SY 19 32 INPUT4_PB 2.5 INPUT4_PB 9
33 GND 0 GND 18 33 GND 0 GND 8
34 INPUT2_V 2.6 INPUT2_V 17 34 INPUT4_PR 2.5 INPUT4_PR 7
35 GND 0 GND 16 35 GND 0 GND 6
36 INPUT2_SC 2.1 INPUT2_SC 15 36 INPUT4_V 2.5 INPUT4_V 5
37 INPUT2_S2 0.2 INPUT2_S2 14 37 GND 0 GND 4
38 INPUT2_SPLUG 4.7 INPUT2_SPLUG 13 38 INPUT4_L 4.5 INPUT4_L 3
39 INPUT2_SY 2.3 INPUT2_SY 12 39 GND 0 GND 2
40 GND 0 GND 11 40 INPUT4_R 4.5 INPUT4_R 1
41 GND 0 GND 10
42 GND 0 GND 9
43 GND 0 GND 8
44 GND 0 GND 7
45 GND 0 GND 6
46 GND 0 GND 5
47 TEMP_2 2.2 TEMP_2 4
48 V+9V_A 9.2 V+9V_A 3
49 V+9V_A 9.2 V+9V_A 2
50 V+3.3V_UCOM 3.3 V+3.3V_UCOM 1
Voltage
(V)
CN8802(AKM1349- -TBB) CN4004(AKM1349- -TBB)
MTB MAIN AssyTANSHI Assy TANSHI Assy MTB MAIN Assy
CN8803(AKM1348- -TBB)
Voltage
(V)
CN4005(AKM1348- -TBB)
