No. Name Name No. No. Name Name No.
No. Name Name No.
1 GND 0 GND 1 1 GND 0 GND 1
12 PC_H 0 PC_H 12
2 GND 0 GND 2 2 GND 0 GND 2
11 PC_V 0 PC_V 11
3 MD3 0 MD3 3 3 VPP 3.3 VPP 3
10 GND 0 GND 10
4 CD1A 3.3 CD1A 4 4 VPP 3.3 VPP 4
9 PC_B 2.4* PC_B 9
5 MD4 3.3 MD4 5 5 MIVALA 0 MIVALA 5
8 GND 0 GND 8
6 MDOA3 0 MDOA3 6 6 MDIA4 0 MDIA4 6
7 PC_G 2.4* PC_G 7
7 MD5 0 MD5 7 7 GND 0 GND 7
6 GND 0 GND 6
8 MDOA4 0 MDOA4 8 8 MICLKA 0 MICLKA 8
5 PC_R 2.4* PC_R 5
9 MD6 3.3 MD6 9 9 GND 0 GND 9
4 GND 0 GND 4
10 MDOA5 0 MDOA5 10 10 MDIA5 0 MDIA5 10
3 V+5V_A 5 V+5V_A 3
11 MD7 3.3 MD7 11 11 MA12 0 MA12 11
2 GND 0 GND 2
12 MDOA6 0 MDOA6 12 12 MDIA6 0 MDIA6 12
1 V+9V_A 9.2 V+9V_A 1
13 CE1A 3.3 CE1A 13 13 TX_Q 0 TX_Q 13
14 MDOA7 0 MDOA7 14 14 MDIA7 0 MDIA7 14
15 MA10 0 MA10 15 15 TX_EN 0 TX_EN 15
16 CE2A 3.3 CE2A 16 16 POD_VS2 3.3 POD_VS2 16
17 OE 3.3 OE 17 17 YX_I 3.3 YX_I 17
18 POD_VS1 3.3 POD_VS1 18 18 RSTA 0 RSTA 18
19 MA11 0 MA11 19 19 OOB_EN 0 OOB_EN 19
20 IORD 3.3 IORD 20 20 WAITA 3.3 WAITA 20
21 POB_DATA 0 POB_DATA 21 21 MA3 0 MA3 21
22 IOWR 3.3 IOWR 22 22 DSUB_DET 0 DSUB_DET 22
23 GND 0 GND 23 23 MA2 0 MA2 23
24 POB_CLK 3.3 POB_CLK 24 24 REG 3.3 REG 24
25 GND 0 GND 25 25 MA1 3.3 MA1 25
26 MISTRTA 0 MISTRTA 26 26 MOVALA 0 MOVALA 26
27 MA13 3.3 MA13 27 27 MA0 0 MA0 27
28 MDIA0 0 MDIA0 28 28 MOSTRTA 0 MOSTRTA 28
29 GND 0 GND 29 29 MDO 0 MDO 29
30 MOCLKA 0 MOCLKA 30 30 MDOA0 0 MDOA0 30
31 GND 0 GND 31 31 MD1 0 MD1 31
32 MDIA1 0 MDIA1 32 32 MDOA1 3.3 MDOA1 32
33 WE 3.3 WE 33 33 MD2 3.3 MD2 33
34 MDIA2 0 MDIA2 34 34 MDOA2 0 MDOA2 34
35 RDY/IRQA 3.3 RDY/IRQA 35 35 WE_ROM 0 WE_ROM 35
36 MDIA3 0 MDIA3 36 36 CD2A 3.3 CD2A 36
37 VCC 3.3 VCC 37 37 GND 0 GND 37
38 VCC 3.3 VCC 38 38 V+3.3V_UCOM 3.4 V+3.3V_UCOM 38
39 VCC 3.3 VCC 39 39 TEMP2_P 2.2 TEMP2_P 39
40 GND 0 GND 40 40 GND 0 GND 40
POD Assy MTB MAIN Assy
CN9001(AKM1348- -TBB)
Voltage
(V)
CN7302(AKM1354- -TFB)
Voltage
(V)
CN9002(AKM1348- -TBB) CN7301(AKM1354- -TFB)
MTB MAIN Ass'yPOD Assy
MTB MAIN Assy
CN9003(CKS3826-)
Voltage
(V)
CN4013(AKM1233- -TBB)
POD Assy
* When PC signal is not inputted.
