Finishing the rudder cables
For aircraft equipped with a nose wheel it is necessary to fit the pedal connectors to the steering
yoke, which comes through the firewall.
 Mark the cable position into the center of the holes in the fittings after securing the
rudder to be perfectly straight and also making sure the nose wheel is straight.
 Double swage using a nicopress.
 Fit the carbon covering between the firewall and the rudder cables. Hold it in place with
screws. The lid of the cable tunnel is fixed with Velcro
 Fit the bolts to hold the cables and secure with red Loctite 262. Use silicone to seal the
edges around the holder where it meets the floor of the aircraft.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 109 of 267
