Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
Rudder pedal preparation
 The holes for the pedals and rudder cables should be already marked on your fuselage.
When drilling the cables for the rudder it is necessary to have the drill laying on the floor
of the cockpit to ensure the holes are drilled in the right direction. If they are on an
angle it will cause unnecessary friction to the rudder cables. If the holes are the right
direction there will be no binding in the cables. All the holes have a diameter of 6mm.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 55 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
