Fitting the lower fuel system
Preparing the firewall:
 Cut 2 holes, 22 mm in diameter, side by side into the firewall as shown in the photo
below. Use a Dremel to grind the center section so you end up with a slot.
 There are three components that you need to complete this step. The first part has a T
piece with 2 silicone tubes and a rubber hose. The second piece is rubber and silicone
tube, which is used for the fuel return line. The third is a smaller junction, which connects
the gasculator and fuel filler/drain.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 49 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
