Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Drill the holes in the firewall for the rudder pedals. These must also go through on the
same angle as the cockpit floor. Note that these holes must go through two layers of
fiberglass thus, if they are done at the wrong angle they will come out the floor of the
fuselage and not in the correct position
Seat belt preparation
 The seat belts have outer anchoring positions which have metal inserts embedded in the
fiberglass. Prepare them by tapping metric 8mm. Be sure not to tap he holes too deep
or you will go through the outer layer of the plane and cause major damage. The factory
uses an electric drill for the tapping, but they recommend that the kit builder should do
this procedure by hand.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 56 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
