Fitting the front cowls
Connecting the two cowls and fitting the seam screws:
 The cowls have small indents along the rim where they connect together. These indents
indicate where the first set of holes are to be drilled. Mark them with a pen and put the
two halves together. Hold them together with tape.
 The two halves should fit together nicely. If this is not the case, use a file to straighten
out any rough edges.
 Drill a 3mm hole through both cowls and secure with a small screw. Repeat this for the
remaining holes. Turn and complete the other side.
 Separate the two sides and redrill the top cover's 3mm holes with a 6.2mm drill bit for
the quick connect screws.
