K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
Cutting the slots for the fuel gauge
 Drill holes for fuel sight gauge in the fuselage wing root. Start with a smaller hole and
open up with the step drill - holes are 12mm diameter. Join the holes using a Dremel and
then file, sandpaper them clean
Step Drill – A useful purchase from most good electrical or larger hardware stores
Fitting the throttle assembly and the flap handle
 Position the throttle-choke assembly and mark holes needed for the throttle and choke
cables. See Appendix 4 for a diagram of the hole locations.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 34 of 267
