Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
Fitting the rudder cables
 firstly lubricate the cables with WD-40 and also the cable outers.
 Feed the cables through from the firewall and into the cabin
 Gently tap the end screws into the fuselage
 Then find the hole that leads into the cabin and, being careful not to puncture/damage
the cabin interior wall, gently tap the end screw through.
 Then feed the cables through the pedal S-pipe, out the end and into the cable outers.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 69 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
