Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
Fitting the brake lines
Feeding lines from under the fuselage, through the cabin floor and into the cabin:
 Feed the brake lines from under the fuselage into the cabin through the holes located
directly in front of the undercarriage legs. It is important to leave a loop in the ends
under the landing leg. If you pull it too tight you may damage the brake lines on the
edge of the drilled hole.
 Drill a 10 mm diameter hole just in front of the rudder cables in the center tunnel for the
exit of one brake line. It should be offset 10 mm to the right of center (when looking
towards the front of the aircraft).
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 111 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
