K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
What do you need?
Space
Pipistrel Sinus aircraft have a wingspan of just under 15 meters, while Virus aircraft have
approximately 12.5. In order to work the wings comfortably, you're going to need a work space
that is at least 9 meters long, because Sinus wings measure approximately 8 meters long. This
would give you a little space at each end to move around a little more if you're making a Virus.
Work Conditions
Working with epoxy requires, that the components epoxy and work space need to be around 21
degrees Celsius until the epoxy completely cures. For all other steps and procedures you aren't
required to heat your workspace.
Work Conditions
Here is a list of tools that will definitely come in handy when making your Pipistrel aircraft:
Vapor mask Tape measure
Variable speed drill Swaging tool
Set of metric drill bits (longer ones if possible) Work lamp (one that you can hang in the aircraft if
need be)
Metric thread taps Scissors or clippers
Metric step drill Paint brushes
Standard metric open-end wrenches Dremel hand drill
Standard metric ratchet sockets Dremel sanding drill bits
Standard metric Allen wrenches Heat gun
Special NutSert installation tool Various files for sanding, grinding and polishing
Right angle hand drill (or drill angle attachment) Felt-tip marker (erasable)
Jigsaw Drill bits for countersinking
De-burring tool Vernier caliper set
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 4 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
