Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
Fitting the ballistic chute (part 1)
If you have ordered a chute with your kit, the factory will have marked the position and shape of
the hole with marker pen on the top of your aircraft.
 Mask over the area with packaging tape to stop the surface getting damaged when you
cut the chute opening with a jig saw.
 Drill 4 small holes and a slot to start the cut with a jigsaw. Be sure to measure the
jigsaw blade width first and use a drill with the same drill piece thickness as the jigsaw
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 37 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
