Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
Installation of the heat duct, oil tank bracket and wire bundle fittings
 Push the carbon heat duct in place with the flange on top of the carpet.
 If need be, open the holes in the insulation blanket and carpet at the remaining holes to
allow for the bolts fit through the firewall
 Use blue Loctite 243 on the bolts.
 Now mount the oil tank bracket using blue Loctite 243 on the bolt threads.
 Next install the through-firewall plastic threaded wire bundle fittings. If you find that
they are not long enough to extend beyond the carpet remove enough carpet material
around the hole to permit installation of the nut on the end of the fitting on the back side
of the firewall.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 33 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
