Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
Wing preparation
Placing the counterbalances:
 Measure and mark the points on the flaps where the center of each counterbalance
should be, according to the diagram provided in Appendix 12.
 When fitting the metal counterbalances they must be fixed to the flap using epoxy and
rivets. The surface of the flap and the metal must be cleaned and roughed up to ensure a
good bond. Lastly, the rivet comes from the plastic side and the end is in the metal
 Be sure to hold the metal in place with vice grips until riveted. Use a 4 mm drill and
rivets which are 4mm by 13mm.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 197 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
