Mounting the electrical panel
Make sure the dash carpet is burnt through on the remaining holes, fit the plastic cable
grommets to stop the cables getting cut through, mount the pre assembled electrical panel
which includes the fuse box, regulator, battery and CDI unit, pull the electrical cables through
the dash for connection to the instruments.
