Fitting the rudder
The rudder requires little preparation as it’s almost ready to fit when you receive it. There is a
little difference between the sinus and virus rudders; the sinus rudder has a fortified base to
compensate for the attachment of the rudder wheel rudder springs
 You need to grind a little material away from the base of the rudder where the bottom
mount is. Grind two pits in the rudder where the bolt heads sit when the rudder is placed
on the pivoting bracket (see photos below). The pits are located between
 It is normal to take about 3mm away from the sides to allow for full movement of the
rudder, it is necessary to get 30 degrees movement in each direction and the limiting
stops get adjusted on the large stainless bracket on the bottom of the rudder post. You
will also need to grind away the base of the rudder. Fit the zigzag rudder tape on the
rudder.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 110 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
