K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 The screws, when fitted, must slide freely, so run a light round file through the hole to
open it up a little if it doesn’t slide
 When the quick release screw is fitted, put on the special split washer to stop the quick
connect from coming off.
 Don't mistake the quick connect screws for the fuselage rim with those for the side
connecting seam (see photo below). The correct quick fit screw and fitting assembly for
the cowl connection seam has a smaller washer.
