K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Drill the center seat belt mounts in the center of the aircraft and position them centrally
in the prepared pad. Drill 8mm on both sides. Be aware, however, that if you drill too far
you will damage the elevator pushrod so don’t push too hard.
 Now drill the rear seat belt mounts just below the rivet installed by the manufacturer,
hole size 8mm
Leave the fitting of the seat belts to much later in the process – its one of the last jobs and they
will be protected from damage while fitting other items.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 57 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
