K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Mount gascolator on the bracket that is attached to the lower left engine mount attach
point. This is accomplished using two 1 cm spacers (Pipistrel part 1033003), two M6 x 30
hex bolts, two 6 mm flat washers, two 6 mm lock washers and two plain nuts. In
addition to the lock washers. Apply blue Loctite 243 on the nuts.
 Cut a length of fuel hose and fire sleeve from the end of the fuel supply line and attach
the fuel flow sensor to the outlet of the gascolator, using cable ties at the fittings.
 Route the fuel flow sensor wire down the engine mount and follow the other wires to the
point where it will go through the firewall, securing the wires to the engine mount tubes
with cable ties.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 166 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
