K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Mount the radiator on the engine mounts using the bolts and washers provided. Apply
blue Loctite 243.
 Connect the long radiator hose to the upper radiator fitting just below the filler cap. Use
a 25-40 mm hose clamp.
 Use the piece of long radiator hose that you trimmed off earlier to connect the main
cooling pipe to the other radiator fitting. Use a 25-40 mm hose clamp.
 Connect the radiator to the overflow bottle using blue plastic tubing. Use a heat gun to fit
it over the spout and then fix it with plastic ties.
 Fill the radiator with the coolant solution and water.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 172 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
