K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
Mounting the lower cowl positioning brackets:
 Refit the cowls and then drill/mount the final positioning brackets as per the attached
 Note that the virus, with its nose leg, doesn’t have a bracket in the middle of the
fuselage.
 Finally grind away the final fit for the nose leg, have clearance of 10 mm on the sides and
20 mm to the front, have the same for the exhaust opening.
