Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
Preparing the wingtips for strobe fitting:
 Cut the wing tips if strobes are to be fitted. First, locate the strobe cables. If no strobe
wires are there, locate the tunnel and run the wires through the wing.
Setting up the airbrakes:
The steps involved in mounting the airbrakes are fairly deruddered and require certain tools. Be
sure to follow the following steps slowly and carefully.
 First mount the air brakes stops. Use blue Loctite.
 Then place a 4mm spacer between the cam and the airbrake stop. Temporarily fix it into
place using a set of clamps as shown below.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 202 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
