K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Now it is necessary to drill 4 holes in the push rod. These holes should have a diameter
of 4mm and be aligned nicely with the holes in the ball-end. Make the special tool shown
in the drawing found in Appendix 14. It will help you with drilling the holes in the proper
places. Place the tool over the end of the push rod and proceed with drilling the holes.
