Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
Fitting the wing connection plate:
 The first step is to drill the holes in the wing root. Use the templates found in Appendix
16 and 17. You'll find one for the left wing and one for the right wing. The templates
need to be lined up with the wing's spar and upper edge.
 Mark and drill 3mm holes and then tap them out to 4mm.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 217 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
