K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Now it is time to level and adjust the flaperons. Put the flap handle to the 0
o
setting and
fix the control sticks in neutral (centered up and down). Then adjust the flaps so that the
flap end closest to the fuselage aligns nicely with the rim on the fuselage (see pictures
below). This is done by screwing and unscrewing the uniballs found at the end of the
vertical flaperon push rods.
 Place levels on the flaperons and check to see that the flap handle accurately controls the
flaperons movement (-5
o
, 0
o
, +9
o
and +18
o
)
