Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Drill the holes using a 6.5 mm drill bit and clean up the mess afterwards with a vacuum.
 Assemble the foundation with the nuts and ring bolts provided. This requires temporarily
unscrewing the control stick drives L-profile fixation bracket, so that you can fit the ring
bolts with the appropriate nut from under the cockpits floor
 Maker sure the foundation sits nicely on the cockpit floor. If need be, open up the holes a
little with a dremel to ensure the bolts can be screwed and unscrewed easily.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 248 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
