Pipistrel Sinus User Manual

K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 Now remount the nose wheel and check its alignment. Adjust the ring bolts you installed
earlier so that the nose wheel always centers itself once the pedals are released.
Mounting the automatic rudder-centering system:
 Each spring runs from the balancing bracket to the rudders lower post
 Mount the springs. Use blue Loctite 243 on the all of nuts and mark them with red paint.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 250 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
