K i t M a n u a l f o r P i p i s t r e l S i n u s a n d V i r u s A i r c r a f t
 The metal support bracket comes with 10 bolts. Secure each with Loctite 262.
Remember to tighten these bolts after about 5 hours of flight because they tend to move
a little when new.
 Fit the rudder stops and the nyloc securing nuts.
 Then fit the rudder attachment bracket. Apply grease to the bushing for lubrication and
attach it to the aircraft, using Loctite 262 on the nuts.
http://www.pipistrel.si © Pipistrel Release March 2009 © Page 74 of 267

Pipistrel Sinus Specifications

General

Manufacturer	Pipistrel
Seats	2
Rate of climb	5.5 m/s (1, 080 ft/min)
Ballistic parachute rescue system	Optional
Engine	Rotax 912
Type	Motor glider
