10. Squeeze the tabs and slide the printhead pegs into the lower set of grooves.
Warning: If you do not seat the printhead correctly it can damage the device.
11. Keep squeezing the tabs and push the printhead flush against the wall. The tabs snap outward
when placed correctly.
