BT37 MarkII: Service Manual MA200606 1.0.0
Introduction
Do not resterilize.
Batch code.
Use by date.
Do not dispose of with general waste.
1.5 Equipment list
To service the BT37 the service personnel will require the following
equipment:
Electronic engineers tool kit.
Digital multimeter.
Static protection wrist band.
Earthing strap.
Toolkit:
Hex Key, 1.5mm, 3mm, 2.5mm (T handle)
Screwdiver: PZ1, PZ2, Jewellers flat
Long nose pliers
Spanners: 9/16 " AF, 6,7 & 8mm
Parts required.
