Planet HDP-1261PT User Manual

1080p SIP Vandalproof Door Phone with RFID and PoE
HDP-1261PT
21
C. Connect the cables of RJ45, power, and electric-lock to the motherboard socket as mentioned in connector
description.
D. Connect the terminal of the wired cable to the motherboard socket.
E. Test whether there is electricity by doing the following: Press the DSS key button for 3 seconds to get the
IP address of intercom by voice. Input access password or press the indoor switch to check electric-lock
installation.
Do not proceed mounting until you have finished
the electrical inspection .
F. Attach the device to the wall bracket in a top-down manner, locking the screws at the Bottom, as shown in
Figure 2-2-6.
Figure 2-2-6
While drilling or fixing the HDP-1261PT, hold it tight or else it may drop and accidentally hurt the
installer.

Planet HDP-1261PT Specifications

General

Brand	Planet
Model	HDP-1261PT
Category	Intercom System
Language	English
