Internet Telephony PBX System
IPX-330/IPX-2100
13
1.2 Package Contents
Thank you for purchasing PLANET Internet Telephony PBX system, IPX-330 and IPX-2100.
This Quick Installation Guide will introduce how to finish the basic setting of connecting the
web management interface and the Internet. Open the box of the Internet Telephony PBX
system and carefully unpack it. The box should contain the following items:
Internet Telephony PBX System Unit x 1
Quick Installation Guide x 1
User’s Manual CD x 1
Power Adapter x 1 (12V)
RJ45 x 1
Bracket x 2 (IPX-2100 only)
If any of the above items are damaged or missing, please contact your dealer immediately.
1.2.1 Physical Specifications of IPX-330
Dimensions
Dimensions (W x D x H)
155 × 295 × 65 mm
Net Weight
0.5 kg (without package)
Front Panel
Rear Panel
LED definitions
Front Panel LED Status Description
PWR
Steady Green
Off
PBX Power ON
PBX Power OFF
