User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-10-
Product Specifications
Product
WDAP-C7210E
1200Mbps 802.11ac Wave 2 Dual Band Ceiling-mount Wireless Access Point
Hardware Specifications
Interfaces LAN
2 x 10/100/1000BASE-T RJ45 port
Auto-negotiation and auto MDI/MDI-X
Antennas
Gain:
4 x Internal 5dBi antenna (2.4G x2, 5G x2)
Reset Button
Reset button on the rear side (Press over 15 seconds to reset the device to factory
default)
LED Indicators
SYS, 2.4G, 5G
Dimensions (W x D x H)
186 x 186 x 35.8mm
Weight
380 ±5g
Power Requirements
48V DC IN, 0.5A, IEEE 802.3at PoE+ or
12V DC IN, 1.5A from DC Jack ( 5.5 x 2.1mm )
Power Consumption
< 12W
Mounting
Ceiling Mount
Wireless Interface Specifications
Standard
IEEE 802.11ac
IEEE 802.11n
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3x flow control
IEEE 802.11k, 802.11v, and 802.11r
Media Access Control
CSMA/CA
Data Modulation
802.11ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)
802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM)
802.11b: DSSS (DBPSK / DQPSK / CCK)
Band Mode
2.4G / 5G concurrent mode
Frequency Range
2.4GHz:
FCC: 2.412~2.462GHz
ETSI: 2.412~2.472GHz
5GHz:
FCC: 5.180~5.240GHz, 5.745~5.825GHz
ETSI: 5.180~5.700GHz
Operating Channels
FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165 (9 Channels)
ETSI: 36, 40, 44, 48, 100, 104, 108, 112, 116, 132, 136, 140 (12 Channels)
5GHz channel list may vary in different countries according to their regulations.
Max. Transmit Power
FCC: up to 22 ± 1dBm
