User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-26-
Connecting to the AP
System Requirements
2.2
 Broadband Internet Access Service (Cable/xDSL/Ethernet connection)
 One IEEE 802.3at PoE switch (supply power to the WDAP Series)
 PCs with a working Ethernet adapter and an Ethernet cable with RJ45 connectors
 PCs running Windows 98/ME, NT4.0, 2000/XP, Windows Vista / Win 7, MAC OS 9 or later, Linux,
UNIX or other platforms compatible with TCP/IP protocols
1. The AP in the following instructions refers to PLANET WDAP-C7210E.
(Please refer to
WDAP-W1200E/WDAP-850AC QIG to install the AP)
2. It is recommended to use Internet Explorer 11, Firefox or Chrome to access the AP.
Installing the AP
2.3
Before installing the AP, make sure your PoE switch is connected to the Internet through the broadband service
successfully at this moment. If there is any problem, please contact your local ISP.
Please install the AP according to the following steps. Don't forget to pull out the power plug and keep your
hands dry.
Step 1. Take the mounting bracket, put it on the target place by aligning the holes and fix it with the supplied
screws.
Figure 3-1 Mounting the Bracket
