Planet WDAP-C7210E User Manual

User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-25-
Port & Connector
Hardware Interface Definition
Object Description
Antenna Connectors
4 N-type (female) antenna connectors
PoE LAN Port
10/100/1000Mbps RJ45 port, auto MDI/MDI-X
802.3at PoE+ supported, 48VDC In
Reset Button
Press and hold the Reset button for over 10 seconds to return to the
factory default setting.
Grounding Terminal
The grounding wire must be attached to this port to prevent damage to
the AP from direct lightning strike.
