User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-50-
Figure 5-23 Repeater Mode
The page includes the following fields:
Object Description
Select Network Select “2.4G” or “5.8G” wireless LAN.
Repeater SSID Enter the root AP’s SSID or press “Scan” to select.
Lock BSSID
Check to lock the root AP’s MAC address.
Encryption
Select the wireless encryption of root AP.
“WPA/WPA2PSK_TKIPAES”.
Password
Enter the password of root AP.
Bandwidth Select the operating channel width, “20MHz” or “40MHz” or “80MHz”.
P2P
Enable switch for Point to Point function.
Press Scan to show the root AP that you need to repeat and press Choice to select the AP.
