Figure 5-59 Adding rule of flow control(Speed Limit)
The page includes the following fields:
Object Description
Status
Select enable or disable flow control rule
IP Group
Select custom or Add an IP group
IP Address
Enter an IP address range or use scan to select
Time Group
Select any or custom or Add a Time group
Limited Mode
Select limited mode for shared limited bandwidth or exclusive limited
bandwidth
Up
Enter the upstream limited for kbps
Down
Enter the downstream limited for kbps
Mark
Enter the mark string, or not
