User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-20-
Front Panel
Figure 2-2 WDAP-C7210E Front Panel
LED Definition
LED STATUS FUNCTION
PWR
On ( Red ) The access point is on.
Off System is operating.
SYS
On Wireless LAN is initializing.
Blinking (Blue/Green)
2.4GHz/5GHz wireless LAN is working.
