User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-80-
Export
Export a log.bin file to you PC
Delete
Press to delete all of the system log
Refresh
Press to refresh the system log
4.7.7.7. Flow Control
Figure 5-57 Setup Flow Control
The page includes the following fields:
Object Description
Add Press the “Add” button to add the rule in the control list
Delete Press the “Delete” button to delete the rule
Apply Press the “Apply” button to enable/disable the rule
Status
Select enable or disable QoS rule
Enable/disable Port Mapping function
Figure 5-58 Enable or Disable QoS Rule
