Product
WDAP-W1200E
Dual Band 802.11ac 1200Mbps Wave 2 In-
wall Wireless Access Point (EU
Type, 802.3af/at)
Hardware Specifications
Interfaces
LAN
2 x 10/100/1000BASE-T RJ45 port
Auto-negotiation and auto MDI/MDI-X
PoE Port
1 x 10/100/1000Mbps auto MDI/MDI-X RJ45 port (rear panel)
※ IEEE 802.3af/at PD port
RJ11 Port Six-position four-conductor (6P4C) modular jack
Antennas
Gain 4 x 2dBi antenna
Button Reset button (Press over 10 seconds to reset the device to the factory default)
LED Indicators
LAN1/LAN2/WAN/SYS
Dimensions (W x D x H)
86 x 45 x 86 mm
Weight
168 ± 5g
Power Requirements
48V DC IN, 0.5A, IEEE 802.3af/at PoE+
Power Consumption
< 8W
Mounting
In-wall mount
Wireless Interface Specifications
Standard
IEEE 802.11ac
IEEE 802.11n
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x flow control
Media Access Control
CSMA/CA
Data Modulation
802.11ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)
802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM)
802.11b: DSSS (DBPSK / DQPSK / CCK)
Band Mode
2.4GHz / 5GHz concurrent mode
Frequency Range
2.4GHz:
FCC: 2.412~2.462GHz
ETSI: 2.412~2.472GHz
5GHz:
FCC: 5.180~5.240GHz, 5.745~5.825GHz
ETSI: 5.180~5.700GHz
Operating Channels
FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165 (9 channels)
ETSI: 36, 40, 44, 48, 100, 104, 108, 112, 116, 132, 136, 140 (12 channels)
5GHz channel list will vary in different countries according to their regulations.
RF Power
<20dBm (EIRP)
Receive Sensitivity
Network Mode Data Rate Receive Sensitivity (dBm)
2.4GHz
