Planet WDAP-C7210E User Manual

User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-16-
Product
WDAP-850AC
1200Mbps Dual Band 802.11ac Wave 2 Outdoor Wireless AP
Hardware
Standard Support
IEEE 802.11ac
IEEE 802.11n
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3x flow control
Material
Aluminum
Dimensions (W x D x H)
231 x 80 x 295 mm
Weight
2.3kg
Power Requirement
48V 0.5A, IEEE 802.3at PoE+
Power Consumption (max.)
< 30W
Mounting Type
Mast mounting
Interface
Wireless IEEE802.11a/b/g/n/ac, 2T2R
PoE WAN: 1 x 10/100/1000BASE-T, auto-MDI/MDIX, 802.3at PoE In
Button
Reset button
Antenna
Built-in four N-type connectors
Data Rate
IEEE 802.11b: up to 11Mbps
IEEE 802.11a/g: up to 54Mbps
IEEE 802.11n (20MHz): up to 150Mbps
IEEE 802.11n (40MHz): up to 300Mbps
802.11ac (VHT20): Up to 173.3Mbps
802.11ac (VHT40): Up to 400Mbps
802.11ac (VHT80): Up to 867Mbps
Media Access Control
CSMA/CA
Modulation
802.11ac: OFDM (BPSK/ QPSK/ 16QAM/ 64QAM/ 256QAM)
802.11a/g/n: OFDM (BPSK/ QPSK/ 16QAM/ 64QAM)
802.11b: DSSS (DBPSK/ DQPSK/ CCK)
Frequency Band
2.4GHz:
FCC: 2.412~2.462GHz
ETSI: 2.412~2.472GHz
5GHz:
FCC: 5.180~5.240GHz, 5.745~5.825GHz
ETSI: 5.180~5.700GHz
